Description:

High cutting capacity for high-climbers

Husqvarna T540 XP® Mark III is a top-handle gas chainsaw with impressive power-to-weight. Ideal for arborists and professional tree care teams who want a reliable, high-performance top-handle chainsaw, that’s easy to maneuver and always does the job well. The 40cc class petrol engine combined with the SP21G chain delivers superb cutting capacity with fast acceleration for safe and efficient treetop work.

Specification:

Model: 12" SP21G SN .325mini (US/CA)

SKU: 970 51 00-16

Engine:

• Cylinder Displacement: 39.1 cm³
• Output Shaft Power: 2.6 hp
• Maximum Torque: 1.9 Nm at 7,500 rpm
• Clutch Engagement Speed: 4,400 rpm (±120)
• Electrode Gap: 0.03 in
• Idling Speed: 3,000 rpm
• Maximum Power Speed: 10,200 rpm
• Oil Pump Type: Adjustable flow, no flow at idle
• Spark Plug: NGK CMR7H

Equipment:

• Recommended Bar Length (Min): 12 in
• Recommended Bar Length (Max): 16 in
• Chain Type: SP21G
• Bar Length: 40 cm (16 in)
• Sprocket Type: Spur 7
• Gauge: .043"

Dimensions:

• Weight (Excl. Cutting Equipment): 8.4 lbs

Sound and Noise:

• Sound Pressure Level at Operator's Ear: 102 dB(A)
• Sound Power Level, Guaranteed (LWA): 112 dB(A)
• Sound Power Level, Measured: 110 dB(A)

Vibration:

• Equivalent Vibration Level (ahv, eq) Rear Handle: 3.4 m/s²
• Equivalent Vibration Level (ahv, eq) Front Handle: 3.5 m/s²

Lubricant:

• Oil Tank Volume: 0.49 US pint
• Lubricant Type (Engine): Husqvarna 2 stroke or equivalent at 50:1

Width	Weight	Height	Length
0 Inch	8.6 Pounds	0 Inch	0 Inch
