Description:

Specifications:

• General Vehicle Weight Ratings (GVWR)
• G.V.W.R.: 7,000 lbs
• G.A.W.R.: 3,500 lbs per axle
• Dimensions
• Length: 16′ to 22′
• Width: 83″ to 102″
• Deck Height: 22″
• Axles
• Axles: (2) 3,500 lb Dexter 1 Electric NEV-R-ADJUST Brakes
• Suspension: Multi-Leaf Spring
• Coupler & Hitch
• Coupler: Bumper Pull & Pintle
• Jack: 5,000 lb Top-wind
• Load Capacity & Weight
• Load Capacity: 3,931 – 4,840 lbs (depending on trailer size)
• Estimated Weight: 2,160 – 3,069 lbs (depending on trailer size)
• Construction Features
• Tongue: 5″ Channel
• Frame: 5″ Channel
• Crossmembers: 3” Channel, 24” On-center
• Tires and Wheels
• Wheels: 15” 5-Hole Wheels
• Tires: ST205/75 R15 LRC
• Deck Features
• Fenders: Removable Smooth Plate
• Deck: Straight Deck
• Ramps: 60″ x 22″ Slide-In Ramps
• Floor: Treated Wood
• Additional Features
• D-Rings: (4) 3″ D-rings
• Lights: LED Stop, Tail, & Clearance Lights
• Wiring: 16 Ga. 5-Way Double-Insulated Wire Harness
• Plug: 7-way Cold Weather Cord
• Safety Chains: (2) 5/16” Grade 30
• Finish & Durability
• Pretreatment: Mechanical and/or Chemical Pretreatment for Maximum Paint Adhesion
• Finish: (Black) Sherwin-Williams Powdura OneCure, Primer with Polyester TGIC Gloss Powder Topcoat
• Available Sizes & Weights
• CH8318052: 83″ x 18′, 2,540 lbs

Width	Weight	Height	Length
0 Inch	2540 Pounds	0 Inch	0 Inch
